Energy Science Kit: Universal Battery Holder w/ Powerpoles®
#58255-1514
$24.95
Powerpole® Connector to Universal Battery Holder, 3.25 in. #22 Wire
This battery holder is for AA, AAA, C, and D cell batteries. It can also be used with coin cell batteries. It uses magnetic contacts to connect to the battery. Battery not included.
Please click here for more information on Powerpole® Connectors.
Powerpole® is a registered trademark of Anderson Power Products.
Powerpole® Connector Features & Benefits
- Genderless Housings: Provide simplified assembly and minimize the number of components
- Stackable Modular Housings: Available in four sizes to right size your connection need
- Connection Versatility: Contacts for wire, PCB, or busbar all fit into the same housings
- Low Resistance Connection: Silver or tin plated contacts inside housings that strongly force the contacts together
- Color Coded Housings: Help ensure that connectors are assembled and mated correctly
- Self Securing Design: Stainless steel springs create a robust force between the contacts that holds the connector in the mated condition, but allows it to be quickly disconnected.
Anderson Powerpole® Connectors and General Installation Tips
Powerpole® Connectors | |||
---|---|---|---|
15A | 30A | 45A | |
Amps (UL) Per Pole | 0 to 55 | 0 to 55 | 0 to 55 |
Volts (UL) Per Pole | 600 | 600 | 600 |
Amps Continuous | 15 | 30 | 45 |
Wire Gauge (AWG) | 20 - 16 | 16 - 12 | 14 - 10 |
Touchsafe Polarized Housing |
Yes Yes |
Yes Yes |
Yes Yes |
PDF Files Links |
Data Sheet https://www.andersonpower.com/ |
||
Buy Powerpole® Pack | View Options |
